Excellon Drills 1,633 g/t Silver Equivalent Over 0.35 Metres at Silver City

Toronto, Ontario – February 9, 2022 – Excellon Resources Inc. (TSX:EXN, NYSE:EXN; FRA:E4X2) (“Excellon” or the “Company”) is pleased to announce results from its 2021 diamond drilling campaign and provide an update on the ongoing exploration program at the Silver City Project in Saxony, Germany.

Highlights

  • Step-out drilling intersected significant silver mineralization at four targets, with results including:
    • 1,633 g/t silver equivalent (“AgEq”) over 0.35 metres (1,470 g/t Ag, 0.2 g/t Au, 2.9% Pb and 2.1% Zn) within 257 g/t AgEq over 2.90 metres (232 g/t Ag, 0.4% Pb and 0.3% Zn) in SC21GVB020 at Peter Vein;
    • 1,296 g/t AgEq over 0.35 metres (1,260 g/t Ag, 0.2 g/t Au, 0.6% Pb and 0.3% Zn) within 592 g/t AgEq over 1.05 metres (508 g/t Ag, 0.1 g/t Au, 1.4% Pb and 1.2% Zn) in SC21GWO033 at Grauer Wolf;
    • 266 g/t AgEq over 0.65 metres (228 g/t Ag, 0.1 g/t Au, 0.7% Pb and 0.5 % Zn) within 169 g/t AgEq over 1.93 metres (137 g/t AgEq, 0.3% Pb and 0.6% Zn) in SC21GWO030 at Grauer Wolf; and
    • 383 g/t AgEq over 0.38 metres (7.0 g/t Ag and 5.0 g/t Au) in SC21REI027 at Reichenbach
  • 24 diamond drill holes totaling 8,360 metres completed on the program to date, with 23 holes intersecting target structures, assays pending on four holes and an additional three holes to be drilled at Grauer Wolf in Q1 2022 to complete the 2021 program
  • Historical data review, structural and geological modelling, and soil sampling and prospecting is in progress on the Bräunsdorf license, with additional soil lines planned for the Oederan, Mohorn and Frauenstein licenses to be used to refine drill targets for the 2022 drilling program

“The results from our 2021 drill program confirmed the continuity of the structures intersected in the initial drilling at Silver City,” stated Jorge Ortega, Vice President Exploration. “Drilling at Grauer Wolf and Peter Vein returned high-grade results over a strike of 170 and 300 metres, respectively, with up to eight metre wide zones of hydrothermal alteration and stockwork. These are clear indicators of the potential of the system to host economic mineralization and our continuing goal is to identify broader zones of mineralization at the high grades we have encountered to date. We are also continuing to review the historical exploration and mining data and collect surface geochemical data ahead of our 2022 exploration drill program.”

Exploration Results

The following table shows highlighted intervals from the 2021 exploration drill program at Silver City with assays received to date:

Hole ID Interval Interval(1) Ag Pb Zn Au AgEq(2) Area
From To metres g/t % % g/t g/t
SC21BRD022 429.33 430.14 0.81 63 0.0 0.0 0.1 73 Bräunsdorf
and 443.78 444.16 0.38 42 0.2 0.2 0.5 87 Bräunsdorf
SC21GVB018 298.62 302.00 3.38 55 0.1 0.2 0.2 78 Peter Vein
including 299.82 300.60 0.78 89 0.2 0.2 0.4 130 Peter Vein
SC21GVB020 333.20 336.10 2.90 232 0.4 0.3 0.0 257 Peter Vein
including 334.56 334.91 0.35 1,470 2.9 2.1 0.2 1,633 Peter Vein
SC21GWO030 269.75 271.60 1.85 100 0.2 0.4 0.1 127 Grauer Wolf
including 271.25 271.60 0.35 440 1.1 1.7 0.4 560 Grauer Wolf
and 284.00 288.00 4.00 44 0.0 0.1 0.0 49 Grauer Wolf
including 287.52 288.00 0.48 110 0.1 0.2 0.0 119 Grauer Wolf
and 293.10 295.03 1.93 137 0.3 0.6 0.0 169 Grauer Wolf
including 293.10 293.75 0.65 228 0.7 0.5 0.1 266 Grauer Wolf
SC21GWO031 255.42 256.31 0.89 128 0.2 1.5 0.1 189 Grauer Wolf
SC21GWO033 146.95 148.00 1.05 508 1.4 1.2 0.1 592 Grauer Wolf
including 146.95 147.30 0.35 1,260 0.6 0.3 0.2 1,296 Grauer Wolf
SC21REI027 162.62 163.00 0.38 7 0.0 0.0 5.0 383 Reichenbach
SC21REI028 60.00 61.20 1.20 66 0.0 0.0 0.2 83 Reichenbach
  1. All intersections reported as core length. Additional drilling on the targets is required to determine true width.
  2. AgEq calculated using $1,800 Au/oz, $24.00 Ag/oz, $0.90 Pb/lb and $1.20 Zn/lb with 100% metallurgical recovery.

Including Munzig, mineralization has now been encountered over 24 kilometres along strike.

Modelling of the structural data at Grauer Wolf indicated the presence of five mineralized structures, with the Erwachte Hoffnung and Albert veins hosting high-grade mineralization consisting of up to eight metre wide zones of strong sericitic alteration with stockwork and massive epithermal quartz veins hosting blebby base metal sulphides and silver sulfosalts. Additionally, three step-out holes at Grauer Wolf are scheduled to be completed in Q1 2022 and will test mineralization 420 metres along strike and 225 metres vertically.

Subject to annual permitting requirements and with final metre numbers still being finalized, the currently proposed 2022 drilling program at Silver City will include step-out drilling at Grauer Wolf, Peter Vein and Reichenbach and follow up drilling on the known mineralized structures on the Oederan, Mohorn and Frauenstein licenses, which were added to the project in 2021.

In preparation for the 2022 drill program, Excellon has completed four orientational soil lines over the Peter Vein target to evaluate the surface geochemical signature of mineralization and assess the effectiveness of various analytical techniques. Four additional lines were completed over Grauer Wolf target area. Two soil sampling lines at Hartha target area are currently in progress, with further eight lines to follow up on the historically mined veins and geophysical anomalies on the Oederan, Mohorn and Frauenstein licenses, which is scheduled to be completed in Q2 2022.

The Silver City Project was mined for high-grade silver from the 11th until the late 19th century, when Germany left the silver standard in 1873 and the gold:silver ratio collapsed. Historical records from the project indicate high-grade silver production over substantial widths throughout the district. Excellon has embarked on the first modern day exploration program focused on precious metals. An overview of the past, present and future on the Silver City Project is available in the following film series:

Excellon holds an option to acquire a 100% interest in the Silver City Project from Globex Mining Enterprises Inc. (TSX: GMX) (OTCQX: GLBXF) and (FRA: G1MN).

Figure 1

Figure 2

Figure 3

Technical Information and Quality Control

The drilling results contained in this news release have been prepared in accordance with National Instrument 43-101 Standards of Disclosure for Mineral Projects ("NI 43-101").

Silver City core samples are prepared and assayed by ALS Global Loughrea, Ireland. The lab is accredited to ISO/IEC 17025:2017. Assay turnarounds have been impacted recently by supply and labour shortages related to COVID-19. The Company has a comprehensive QA/QC program, supervised by an independent Qualified Person.

The sampling of, and assay data from, the core sampling and reporting is monitored through a quality assurance and quality control (QAQC) program designed according to best industry practice. Samples from HQ and NQ sized drill core are selected by Excellon geologists and cut into halves at the project site. Half of the core is retained at the site for reference purposes. Sample intervals vary from 0.35 to 1.2 metres in length with samples being selected to honour geological contacts. Samples are labeled and packed into sealed plastic bags which are grouped into larger fiber bags for shipping. A formal chain-of-custody procedure is in place for security of samples from project to laboratory.

Samples are shipped to ALS Laboratories in Loughrea, Ireland. Samples then undergo crushing to less than two millimetres followed by pulverizing a one kilogram split to better than 85% passing 75 microns. Homogenised sub-samples are then analyzed using fire assay (30g sample) for silver with a gravimetric finish and gold with an ICP-AES finish. High-grade gold results are re-analysed by fire assay (30g sample) with a gravimetric finish. Multi-element analysis of samples are performed after four acid digestion by ICP analysis for base metals and multi-element data.

Qualified Person

Mr. Jorge Ortega, P.Geo., Vice President Exploration, has acted as the Qualified Person, as defined in NI 43-101, with respect to the disclosure of the scientific and technical information contained in this press release.
